1B22AN ,Active Chip - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

173 points

Part No

1B22AN
Manufacturer

ADI
ChipWorker Part#

CW605303
Category

Active Chip
Package

DIP-12
Description

ANALOG DEVICES 1B22AN Special Function IC, Voltage to Current Converter, 0 V to 10V input, 0 mA to 20mA output, DIP-12
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 587.82

Buy 1B22AN
