2N7002 - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

2N7002
Manufacturer

Fairchild
ChipWorker Part#

CW977883
Category

MOSFET, MOSFET Transistor
Package

SOT-23-3
Description

Trans MOSFET N-CH 60V 0.115A 3Pin SOT-23 T/R
Documentation

Datasheet

2N7002 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

2N7002 Specifications

Attribute	Attribute Value

Part Number	2N7002
Manufacturer	Fairchild
ChipWorker Part#	CW977883
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Voltage Rating (DC)	60.0 V
Current Rating	115 mA
Power Rating	200 mW
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	1.2 Ω
Polarity	N-Channel
Power Dissipation	200 mW
Threshold Voltage	2.1 V
Drain to Source Voltage (Vds)	60 V
Breakdown Voltage (Drain to Source)	60.0 V
Breakdown Voltage (Gate to Source)	±20.0 V
Continuous Drain Current (Ids)	120 mA
Input Capacitance (Ciss)	50pF @25V(Vds)
Input Power (Max)	200 mW
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	0.2 W
	expand all
Size-Length	2.92 mm
Size-Width	1.3 mm
Size-Height	0.93 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
HK STC License	NLR

Product Description

The 2N7002 is a N-channel enhancement mode Field Effect Transistor produced using high cell density and DMOS technology. It minimizes on-state resistance while providing rugged, reliable and fast switching performance. It can be used in most applications requiring up to 400mA DC and can deliver pulsed currents up to 2A. Suitable for low-voltage, low-current applications, such as small servo motor control and power MOSFET gate drivers.
High density cell design for extremely low RDS (ON)
High saturation current capability
Voltage controlled small signal switch
Rugged and reliable
