302109000 ,Thumbwheel Switch, Pushwheel Switch - C&K Components
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
117 points
-
Part No302109000
-
ManufacturerC&K Components
-
ChipWorker Part#CW4245692
-
CategoryThumbwheel Switch, Pushwheel Switch
-
DescriptionSwitch Thumb-Pushwheel Thumbwheel BCD 10 0.1A 120VAC 28VDC PC Board Panel Mount
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие1361 pcs In Stock
-
Estimated Price$ 18.6
Payment Methods and Delivery
{{ estimate }}
Buy 302109000
Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.
Real stock check
Best price from distributors
Engineer support
302109000 Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}xx
{{ low_stock_text }}
|
1 |
{{weeks_text}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
{{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
|
Chipworker
|
{{noList.partNo}}
{{noList.mfr}}
|
{{stockAvailability}}
{{ search_item }}
|
{{moq}} | 1 | 6 - 8 {{delivery_date}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
|||||||
{{ apiText }}{{ apiTime }}(UTC+8)
Update Data
Chipworker Certification
11+ years sourcing experience
1000+ russia customers
ISO certified supplier
Support small MOQ
*Photos of Our Actual 800 m² Warehouse
302109000 Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | 302109000 | |
| Manufacturer | C&K Components | |
| ChipWorker Part# | CW4245692 | |
| Category | Thumbwheel Switch, Pushwheel Switch | |
| Documentation | Datasheet | |
| Mounting Style | Snap-In | |
| Current Rating | 100 mA | |
| Number of Positions | 10 Position | |
| Contact Current Rating | 1.00 A | |
| Current Rating (Max) | 0.1 A | |
| Operating Temperature (Max) | 65 ℃ | |
| Operating Temperature (Min) | -40 ℃ | |
| Voltage Rating | 120 VAC | |
| Voltage Rating (DC Max) | 28 V | |
| Voltage Rating (AC Max) | 120 V | |
| Maximum Contact Resistance (Max) | 100 mΩ | |
| expand all | ||
| Size-Length | 37.8 mm | |
| Size-Height | 33.0 mm | |
| Color | Black | |
| Operating Temperature | -40℃ ~ 65℃ | |
| Housing Material | ABS Plastic | |
| Product Lifecycle Status | Active | |
| Packaging | Bulk | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| HTS Code | 8536509065 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- 3 Series Thumbwheel Switches, 10^9 Ohms (Min.) Insulation Resistance
- Multisection switches can be made by ordering number of sections desired and accessories such as end plates and blank sections.* Description. Thumbwheel:** Matte black with unsealed switch contacts. ** Operating Voltage:** 50 mV to 28 VDC or 120 VAC. ** Operating Temperature:** –10°C to 65°C. ** Body and Wheel:** ABS plastic. ** Rotor Contacts:** Precious metal on copper alloy. ** Stator Contacts:** Hard gold over nickel over 2 ozs. copper on epoxy fiberglass. ** Contact Rating:** 1 A continuous carry, 100 mA max. switched current. ** Insulation Resistance:** 1
- * 10 9 ohms min. ** Dielectric Strength:** 500 V RMS min. at sea-level between common terminal and any output.
