3209604 - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

3209604
Manufacturer

Phoenix
ChipWorker Part#

CW40892866
Category

Terminal Block, Connector Terminal
Package

-
Description

Conn Terminal Block 4POS Screw T DIN Rail 22A
Documentation

Datasheet

3209604 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

3209604 Specifications

Attribute	Attribute Value

Part Number	3209604
Manufacturer	Phoenix
ChipWorker Part#	CW40892866
Category	Terminal Block, Connector Terminal
Documentation	Datasheet
Mounting Style	DIN Rail
Case/Package	-
Number of Contacts	4 Contact
Wire Gauge	12AWG ~ 26AWG
Current Rating	22 A
Flammability Rating	UL 94 V-0
Number of Positions	4 Position
Current Rating (Max)	24 A
Voltage Rating (Max)	500 V
Voltage Rating	500 V
Operating Voltage (Max)	500 V
	expand all
Size-Length	78 mm
Size-Width	5.2 mm
Size-Height	62.5 mm
Housing Color	Gray
Color	Gray
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
HTS Code	8536904000
ECCN Code	EAR99

Product Description

Reduce fatigue, save time and simplify wiring with Phoenix Contact"s push-in terminal blocks. These tool-less terminal blocks use a direct push-in connection and require 50 percent lower insertion force when connecting solid conductors or conductors with ferrules. As part of the CLIPLINE Complete system, push-in terminal blocks are compatible with standard system accessories, including bridging, checking and marking. They deliver maximum flexibility in a variety of options, including feed-through, multi-conductor, component and pluggable terminal blocks, and can be combined with screw, spring-cage and fast connection terminal blocks.*Features:**
* Orange Push Button Located on the Actuation Shaft Opens the Spring to the Maximum Wiring Space of (4 mm2)/AWG 12 for Fast, Clear Wiring and High-Contacting Safety
* Three Standard Marker Grooves Allow Individual Terminal Point Labeling with the One Marking Material
* Front Connection for Space-Saving Convenient Wiring
