74HC04D - NXP

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

74HC04D
Manufacturer

NXP
ChipWorker Part#

CW7361030
Category

Logic Control, Logic Gate IC
Package

SOIC-14
Description

NXP 74HC04D Inverter, 74HC04, 1Input, 5.2mA, 2V to 6V, SOIC-14
Documentation

Datasheet

74HC04D Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

74HC04D Specifications

Attribute	Attribute Value

Part Number	74HC04D
Manufacturer	NXP
ChipWorker Part#	CW7361030
Category	Logic Control, Logic Gate IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	5.00 V
Output Current	5.2 mA
Number of Positions	14 Position
Number of Gates	6 Gate
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	6 V
Supply Voltage (Min)	2 V
	expand all
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The 74HC04 is a hex inverter. The inputs include clamp diodes that enable the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Complies with JEDEC standard JESD7A
Complies with JEDEC standard JESD8-1A
