76SB02ST ,DIP Switch, SIP Switch - Grayhill
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
132 points
-
Part No76SB02ST
-
ManufacturerGrayhill
-
ChipWorker Part#CW4307426
-
CategoryDIP Switch, SIP Switch
-
PackageDIP
-
DescriptionDIP / SIP Switch, Raised Rocker, 2Circuits, SPST, Through Hole, 76 Series, DIP Sealed, 30VDC
-
DocumentationDatasheet
-
Ships fromMoscow
-
НаличиеIn Stock
-
Estimated Price$ 0.7
