A000066 - Arduino

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

A000066
Manufacturer

Arduino
ChipWorker Part#

CW1982834
Category

Microprocessor Primary Platform
Package

DIP
Description

ATmega328 Microcontroller Uno Development Board 16MHz CPU 2KB RAM 1KB/32KB EEPROM/Flash
Documentation

Datasheet

A000066 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

A000066 Specifications

Attribute	Attribute Value

Part Number	A000066
Manufacturer	Arduino
ChipWorker Part#	CW1982834
Category	Microprocessor Primary Platform
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	DIP
RAM Memory Size	2 KB
Number of Bits	8 Bit
Core Architecture	AVR
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC

Product Description

A000066 Arduino Uno is a microcontroller board based on the ATmega328. It has 14 digital io pins, 6 analogue inputs, a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header and a reset button. It contains everything needed to support the microcontroller, simply connect it to a computer with a USB cable or power it with a AC to DC adapter or battery to get started. The Uno differs from all preceding boards in that it does not use the FTDI USB to serial driver chip. Instead, it features the ATmega16U2 programmed as a USB to serial converter.
Microcontroller Atmel ATmega328
Operating voltage of 5V
Maximum supply voltage 6 to 20V
Digital I/O pins 14 (of which 6 provide PWM output)
DC current per I/O pin 40 mA
DC current for 3.3V pin 50 mA
Flash memory16KB of which 2KB is used by Boot loader
SRAM 2KB, EEPROM 1KB
Clock speed 16MHz
Can be powered via the USB connection or with an external power supply
