ACT512 Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | ACT512 |
| Manufacturer | Panasonic |
| ChipWorker Part# | CW11405735 |
| Category | Power Relay |
| Documentation | Datasheet |
| Mounting Style | Through Hole |
| Number of Pins | 10 Pin |
| Voltage Rating (DC) | 14 V |
| Contacts Type | SPDT |
| Power Consumption | 800 mW |
| Contact Current Rating | 20 A |
| Coil Voltage | 12 VDC |
| Coil Current | 66.7 mA |
| Coil Resistance | 180 Ω |
| Coil Voltage (DC) | 12 V |
| Coil Power | 800 mW |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| expand all | |
| Size-Length | 17.4 mm |
| Size-Width | 14 mm |
| Size-Height | 13.5 mm |
| Contact Material | Silver Alloy |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| HTS Code | 8536410050 |
| ECCN Code | EAR99 |
Product Description
- The ACT512 is a 1-pole super miniature twin type Automotive Relay, CT series. 1 form-C contact configuration, Ag-alloy (cadmium-free) contact. Twin type 10-terminal. Forward/reverse motor control is possible with a single relay. Simple footprint enables ease of PC board layout.
