AD5321BRMZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD5321BRMZ
Manufacturer

ADI
ChipWorker Part#

CW312000
Category

Digital to Analog, DAC IC
Package

MSOP-8
Description

ANALOG DEVICES AD5321BRMZ Digital to Analog Converter, 12Bit, 125KSPS, Serial, 2.5V to 5.5V, MSOP, 8Pins
Documentation

Datasheet

AD5321BRMZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD5321BRMZ Specifications

Attribute	Attribute Value

Part Number	AD5321BRMZ
Manufacturer	ADI
ChipWorker Part#	CW312000
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Voltage (DC)	5.50V (max)
Number of Outputs	1 Output
Supply Current	150 µA
Number of Channels	1 Channel
Number of Positions	8 Position
Number of Bits	12 Bit
Power Dissipation	1.4 mW
Sample Rate	125 kHz
Resolution (Bits)	12.0 Bit
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	1 DAC
Supply Voltage	2.5V ~ 5.5V
	expand all
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17

Product Description

The AD5321BRMZ is a single 12-bit buffered voltage-output Digital-to-analog Converter (DAC) operates from a single 2.5 to 5.5V supply, consuming 120µA at 3V. The on-chip output amplifier allows rail-to-rail output swing with a slew rate of 0.7V/µs. It uses a 2-wire serial interface that operates at clock rates up to 400kHz. The reference for the DAC is derived from the power supply inputs and thus gives the widest dynamic output range. This part incorporates a power-on reset circuit, which ensures that the DAC output powers up to 0V and remains there until a valid write takes place. The parts contain a power-down feature that reduces the current consumption of the device to 50nA at 3V and provides software-selectable output loads while in power-down mode. The low power consumption in normal operation makes this DAC ideally suited to portable battery-operated equipment.
Data read-back capability
Guaranteed monotonic by design over all codes
Reference derived from power supply
Power-ON reset to 0V
3 Power-down functions
