AD5694RBRUZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD5694RBRUZ
Manufacturer

ADI
ChipWorker Part#

CW793833
Category

Digital to Analog, DAC IC
Package

TSSOP-16
Description

ANALOG DEVICES AD5694RBRUZ Digital to Analog Converter, Quad, 12Bit, Serial, 2.7V to 5.5V, TSSOP, 16Pins
Documentation

Datasheet

AD5694RBRUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD5694RBRUZ Specifications

Attribute	Attribute Value

Part Number	AD5694RBRUZ
Manufacturer	ADI
ChipWorker Part#	CW793833
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Number of Outputs	4 Output
Supply Current	590 µA
Number of Channels	4 Channel
Number of Positions	16 Position
Number of Bits	12 Bit
Power Dissipation	7.20 mW
Resolution (Bits)	12.0 Bit
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	4 DAC
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Length	5.1 mm
Size-Width	4.5 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99

Product Description

The AD5694RBRUZ is a low power quad 12-bit buffered voltage output Digital-to-analog Converter (DAC) operates from a single 2.7 to 5.5V supply, is guaranteed monotonic by design and exhibit less than 0.1% FSR gain error and 1.5mV offset error performance. It includes a 2.5V, 2ppm/°C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5 or 5V. It incorporates a power-on reset circuit and a RSTSEL pin that ensures that the DAC outputs power up to zero scale or midscale and remain there until a valid write takes place. It contains a per-channel power-down feature that reduces the current consumption of the device to 4µA at 3V while in power-down mode. It uses a versatile 2-wire serial interface that operates at clock rates up to 400kHz and includes a VLOGIC pin intended for 1.8/3/5V logic.
