AD592CNZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD592CNZ
Manufacturer

ADI
ChipWorker Part#

CW294556
Category

Temperature Sensor
Package

TO-92-3
Description

ANALOG DEVICES AD592CNZ Temperature Sensor IC, Current, ± 0.3℃, -25℃, +105℃, TO-92, 3Pins
Documentation

Datasheet

AD592CNZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD592CNZ Specifications

Attribute	Attribute Value

Part Number	AD592CNZ
Manufacturer	ADI
ChipWorker Part#	CW294556
Category	Temperature Sensor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-92-3
Supply Voltage (DC)	4.00V (min)
Output Current	298 µA
Number of Positions	3 Position
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-25 ℃
Accuracy	±0.5℃ (Max)
Supply Voltage	4V ~ 30V
Supply Voltage (Max)	30 V
Supply Voltage (Min)	4 V
	expand all
Size-Length	5.21 mm
Size-Width	4.19 mm
Size-Height	4.83 mm
Operating Temperature	-25℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
HK STC License	NLR

Product Description

The AD592CNZ is a 2-terminal Monolithic IC Temperature Transducer that provides an output current proportional to absolute temperature. For a wide range of supply voltages the transducer acts as a high impedance temperature dependent current source of 1µA/K. Improved design and laser wafer trimming of the IC"s thin film resistors allows the AD592 to achieve absolute accuracy levels and nonlinearity errors previously unattainable at a comparable price. The inherent low cost of a monolithic integrated circuit combined with a low total parts count in any given application.
High pre-calibrated accuracy
Excellent linearity
Single supply operation
Excellent repeatability and stability
High level output
Minimal self-heating errors
