AD688BQ ,Voltage Reference - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

189 points

Part No

AD688BQ
Manufacturer

ADI
ChipWorker Part#

CW857745
Category

Voltage Reference
Package

CDIP-16
Description

Analog Devices AD688BQ, Fixed Series Voltage Reference 10V, 0.02% 36V max., 16Pin CERDIP
Documentation

Datasheet
Ships from

Moscow
Наличие

175965 pcs In Stock
Estimated Price

$ 5.55

Buy AD688BQ
