AD7190BRUZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD7190BRUZ
Manufacturer

ADI
ChipWorker Part#

CW144265
Category

Analog to Digital, ADC IC
Package

TSSOP-24
Description

Analog to Digital Converter, 24Bit, 4.8KSPS, Single, 4.75V, 5.25V, TSSOP
Documentation

Datasheet

AD7190BRUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD7190BRUZ Specifications

Attribute	Attribute Value

Part Number	AD7190BRUZ
Manufacturer	ADI
ChipWorker Part#	CW144265
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	TSSOP-24
Supply Voltage (DC)	4.75V (min)
Supply Current	6.75 mA
Number of Circuits	1 Circuit
Number of Channels	5 Channel
Number of Positions	24 Position
Number of Bits	24 Bit
Power Dissipation	36.8 W
Sample Rate	4.8 ksps
Resolution (Bits)	24.0 Bit
Number of ADCs	1 ADC
Number of Inputs	2, 4 Input
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	36.8 mW
Number of Input Channels	5 Channel
Supply Voltage	4.75V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	expand all
Size-Length	7.8 mm
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2017/07/07

Product Description

The AD7190BRUZ is an ultralow noise 24-bit sigma-delta Analog-to-digital Converter (ADC) with PGA. The on-chip low noise gain stage means that signals of small amplitude can be interfaced directly to the ADC. The device can be configured to have two differential inputs or four pseudo differential inputs. The on-chip channel sequencer allows several channels to be enabled and the converter sequentially converts on each enabled channel. This simplifies communication with the part. The on-chip 4.92MHz clock can be used as the clock source to the ADC or alternatively an external clock or crystal can be used. The device has two digital filter options. The choice of filter affects the rms noise/noise-free resolution at the programmed output data rate, the settling time and the 50/60Hz rejection.
