Part NoAD7191BRUZ
-
ManufacturerADI
-
ChipWorker Part#CW719458
-
CategoryAnalog to Digital, ADC IC
-
PackageTSSOP-24
-
DescriptionANALOG DEVICES AD7191BRUZ Analog to Digital Converter, 24Bit, 120 SPS, Single, 3V, 5.25V, TSSOP
-
