AD8055 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD8055
Manufacturer

ADI
ChipWorker Part#

CW389452788
Description

Low Cost, 300MHz Voltage Feedback Amplifiers
Documentation

Datasheet

AD8055 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD8055 Specifications

Attribute	Attribute Value

Part Number	AD8055
Manufacturer	ADI
ChipWorker Part#	CW389452788
Documentation	Datasheet
Case/Package	SOIC
	expand all
Product Lifecycle Status	Unknown

Product Description

GENERAL DESCRIPTION
The AD8055 (single) and AD8056 (dual) voltage feedback amplifiers offer bandwidth and slew rate typically found in current feedback amplifiers. Additionally, these amplifiers are easy to use and available at a very low cost.
Despite their low cost, the AD8055 and AD8056 provide excellent overall performance. For video applications, their differential gain and phase error are 0.01% and 0.02° into a 150 Ω load and 0.02% and 0.1° while driving four video loads (37.50 Ω).
FEATURES
Low cost single (AD8055) and dual (AD8056)
Easy-to-use voltage feedback architecture
High speed
300 MHz, −3 dB bandwidth (G = +1)
1400 V/μs slew rate
20 ns settling to 0.1%
Low distortion: −72 dBc @ 10 MHz
Low noise: 6 nV/√Hz
Low dc errors: 5 mV max VOS, 1.2 μA max IB
Small packaging
AD8055 available in 5-lead SOT-23
AD8056 available in 8-lead MSOP
Excellent video specifications (RL = 150 Ω, G = +2)
Gain flatness 0.1 dB to 40 MHz
0.01% differential gain error
0.02° differential phase error
Drives 4 video loads (37.5 V) with 0.02% differential
Gain and 0.1° differential phase
Low power, ±5 V supplies 5 mA typ/amplifier power supply current
High output drive current: over 60 mA
APPLICATIONS
Imaging
Photodiode preamps
Video line drivers
Differential line drivers
Professional cameras
Video switchers
Special effects
A-to-D drivers
Active filters
