AD8130ARM - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD8130ARM
Manufacturer

ADI
ChipWorker Part#

CW18714663
Category

Amplifier, Buffer IC
Package

MSOP-8
Description

SP Amp DIFF Receiver Amp Single ±12.6V/25.2V 8Pin MSOP Tube
Documentation

Datasheet

AD8130ARM Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD8130ARM Specifications

Attribute	Attribute Value

Part Number	AD8130ARM
Manufacturer	ADI
ChipWorker Part#	CW18714663
Category	Amplifier, Buffer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Output Current	35mA @5V
Supply Current	13 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Common Mode Rejection Ratio	86 dB
Slew Rate	1.09 kV/μs
Gain Bandwidth Product	110 MHz
Input Offset Voltage	400 µV
Input Bias Current	500 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	290 MHz
Minimum CMRR Range	86 dB
Supply Voltage (Max)	20V ~ 30V
Supply Voltage (Min)	4.5 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Product Description

Product Details
The AD8129/AD8130 are designed as receivers for the transmission of high speed signals over twisted-pair cables to work with the AD8131 or AD8132 drivers. Either can be used for analog or digital video signals and for high speed data transmission.
The AD8129/AD8130 are differential-to-single-ended amplifiers with extremely high CMRR at high frequency. Therefore, they can also be effectively used as high speed instrumentation amps or for converting differential signals to single-ended signals.
### Features and Benefits
High Speed
AD8130: 270 MHz, 1090 V/µs @ G = +1
AD8129: 200 MHz, 1060 V/µs @ G = +10
High CMRR
94 dB min, dc to 100 kHz
80 dB min @ 2 MHz
70 dB @ 10 MHz
High input impedance: 1 MΩ differential
Low noise
AD8130: 12.5 nV/√Hz
AD8129: 4.5 nV/√Hz
Input common-mode range ±10.5 V
Low distortion, 1 V p-p @ 5 MHz:
AD8130, -79 dBc worst harmonic @ 5 MHz
AD8129, -74 dBc worst harmonic @ 5 MHz
User-adjustable gain
No external components for G = +1
Power supply range +4.5 V to ±12.6 V
Power-down
