AD8306AR ,Amplifier, Buffer IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

150 points

Part No

AD8306AR
Manufacturer

ADI
ChipWorker Part#

CW18924800
Category

Amplifier, Buffer IC
Package

SOIC-16
Description

SOIC 400MHz 95dB DEMODULATING LOG AMP
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 25.07

Buy AD8306AR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD8306AR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD8306AR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD8306AR
Manufacturer	ADI
ChipWorker Part#	CW18924800
Category	Amplifier, Buffer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Output Current	1mA @5V
Supply Current	16.0 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Power Dissipation	0.8 W
Quiescent Current	16.0 mA
Bandwidth	400 MHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	3.5 MHz
Power Dissipation (Max)	800 mW
Supply Voltage (Max)	5V ~ 7V
Supply Voltage (Min)	2.7 V
	expand all
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Similar & Replacement Parts

Similar products

Product Description

Product Details
The AD8306 is a complete IF limiting amplifier, providing both an accurate logarithmic (decibel) measure of the input signal (the RSSI function) over a dynamic range of 100 dB, and a programmable limiter output, useful from 5 MHz to 400 MHz.
An evaluation board is available for this product and may be ordered using the following product number: AD8306-EVAL. Schematic and layout for this evaluation board is contained in the product datasheet.
### Features and Benefits
Complete, Fully Calibrated Log-Limiting IF Amplifier
100 dB Dynamic Range: –91 dBV to +9 dBV
Stable RSSI Scaling Over Temperature and Supplies:
20 mV/dB Slope, –95 dBm Intercept
±0.4 dB RSSI Linearity up to 200 MHz
Fully Differential Inputs, RIN = 1 kΩ, CIN = 2.5 pF
Single Supply of +2.7 V to +6.5 V at 16 mA Typical
Programmable Limiter Gain and Output Current
Differential Outputs to 10 mA,
2.4 V p-p
Overall Gain 90 dB, Bandwidth 400 MHz
Constant Phase (Typical ±56 psDelay Skew)
500 ns Power-Up Time, <1 mA Sleep Current

expand all
