AD8313ARMZ ,Detector chip - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

263 points

Part No

AD8313ARMZ
Manufacturer

ADI
ChipWorker Part#

CW377257
Category

Detector chip
Package

MSOP-8
Description

RF Detector IC RADAR, 802.11/WiFi, 8.2.16/WiMax, Wireless LAN 100MHz ~ 2.5GHz -65dBm ~ 0dBm ±1dB 8-TSSOP, 8-MSOP (0.118", 3mm Width)
Documentation

Datasheet
Ships from

Moscow
Наличие

5 pcs In Stock
Estimated Price

$ 14.78

Buy AD8313ARMZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD8313ARMZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD8313ARMZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD8313ARMZ
Manufacturer	ADI
ChipWorker Part#	CW377257
Category	Detector chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Frequency	100MHz ~ 2.5GHz
Supply Voltage (DC)	2.70V (min)
Output Current	10mA @5V
Supply Current	13.7 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	200 mW
Slew Rate	2.50 V/μs
Input Bias Current	10000 nA
Input Power (Max)	0 dBm
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	200 mW
Accuracy	±1 dB
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The AD8313ARMZ is a 70dB Demodulating Logarithmic Detector/Controller that can accurately convert an RF signal at its input to an equivalent decibel-scaled value at its DC output. It maintains a high degree of log conformance for signal frequencies from 0.1GHz to 2.5GHz. Application is straightforward, requiring only a single supply of 2.7 to 5.5V and the addition of a suitable input and supply decoupling. Operating on a 3V supply, its 13.7mA consumption (for TA=25°C) is only 41mW. A power-down feature is provided, the input is taken high to initiate a low current (20µA) sleep mode with a threshold at half the supply voltage. The AD8313 is fabricated on advanced 25GHz silicon bipolar IC process. This is ideal for RF transmitter power amplifier setpoint control and level monitoring as well as logarithmic amplifier for RSSI measurement cellular base stations, radio link and radar.
