AD8551ARMZ - ADI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoAD8551ARMZ
-
ManufacturerADI
-
ChipWorker Part#CW810050
-
CategoryOperational Amplifier, OP Amp IC
-
PackageMSOP-8
-
DescriptionANALOG DEVICES AD8551ARMZ Operational Amplifier, Single, 1 Amplifier, 1.5MHz, 0.4V/µs, 2.7V to 5V, MSOP, 8Pins
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
AD8551ARMZ Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
AD8551ARMZ Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | AD8551ARMZ |
| Manufacturer | ADI |
| ChipWorker Part# | CW810050 |
| Category | Operational Amplifier, OP Amp IC |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | MSOP-8 |
| Output Current | 30mA @5V |
| Supply Current | 850 µA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Positions | 8 Position |
| Common Mode Rejection Ratio | 120 dB |
| Bandwidth | 1.5 MHz |
| Slew Rate | 400 mV/μs |
| Gain Bandwidth Product | 1.5 MHz |
| Input Impedance | 1.00 TΩ |
| Input Offset Voltage | 1 mV |
| Input Bias Current | 10 pA |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Gain Bandwidth | 1.5 MHz |
| Minimum CMRR Range | 120 dB |
| Supply Voltage | 2.7V ~ 5V |
| expand all | |
| Size-Length | 3 mm |
| Size-Width | 3 mm |
| Size-Height | 0.85 mm |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Contains Lead |
| REACH SVHC Compliance | No SVHC |
| Mil-Spec | No |
| REACH SVHC Compliance Edition | 2015/12/17 |
Product Description
- The AD8551ARMZ is a zero-drift single Operational Amplifier with rail-to-rail input/output. It is guaranteed to operate from 2.7 to 5V with a single supply. The AD8551 provide the benefits previously found only in expensive auto-zeroing or chopper-stabilized amplifiers. No external capacitors are required. With an offset voltage of only 1µV and drift of 0.005µV/°C, the AD8551 is perfectly suited for applications in which error sources cannot be tolerated. Temperature, position and pressure sensors and strain gage amplifier benefit greatly from nearly zero drift over their operating temperature range. The rail-to-rail input and output swings provided by the AD8551 make both high-side and low-side sensing easy.
- High accuracy
- No external capacitors required
- 1µV Low offset voltage
- 0.005µV/°C Input offset drift
- 130dB High gain, CMRR and PSRR
- 20pA Ultralow input bias current
- 700µA/amplifier Low supply current
- 50µs Overload recovery time
