ADG1208YRUZ - ADI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoADG1208YRUZ
-
ManufacturerADI
-
ChipWorker Part#CW319765
-
CategoryAnalog Switch Ic, Analog Switch Multiplexer
-
PackageTSSOP-16
-
DescriptionANALOG DEVICES ADG1208YRUZ 8:1 Analog Multiplexer IC, Single, 120Ω, 10.8V to 13.2V, TSSOP-16
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
ADG1208YRUZ Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
ADG1208YRUZ Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | ADG1208YRUZ |
| Manufacturer | ADI |
| ChipWorker Part# | CW319765 |
| Category | Analog Switch Ic, Analog Switch Multiplexer |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | TSSOP-16 |
| Supply Voltage (DC) | 16.5V (max) |
| Number of Outputs | 1 Output |
| Supply Current | 220 µA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Positions | 16 Position |
| Power Dissipation | 4.70 mW |
| Bandwidth | 550 MHz |
| Number of Inputs | 8 Input |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| 3dB Bandwidth | 550 MHz |
| Supply Voltage | 12V ~ 15V |
| expand all | |
| Size-Length | 5 mm |
| Size-Width | 4.4 mm |
| Size-Height | 1.05 mm |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
Product Description
- The ADG1208 series Analog Multiplexer comprising eight single channels. The IC switches one of eight inputs to a common output as determined by the 3-bit binary address lines A0, A1 and A2. The industrial CMOS (iCMOS) modular manufacturing process combines high voltage complementary metal-oxide semiconductor (CMOS) and bipolar technologies. It enables the development of a wide range of high performance analog ICs capable of 33V operation in a footprint that no other generation of high voltage devices has been able to achieve. The ultralow capacitance and exceptionally low charge injection of these multiplexers make them ideal solutions for data acquisition and sample-and-hold applications, where low glitch and fast settling are required.
- <1pC Charge injection over full signal range
- 1pF Off capacitance
- 120R ON resistance
- Fully specified at ±15V, +12V
- 3V Logic-compatible inputs
- Rail-to-rail operation
- Break-before-make switching action
