ADG721BRMZ - ADI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoADG721BRMZ
-
ManufacturerADI
-
ChipWorker Part#CW124158
-
CategoryAnalog Switch Ic, Analog Switch Multiplexer
-
PackageMSOP-8
-
DescriptionANALOG DEVICES ADG721BRMZ Analog Switch, Dual Channel, SPST, 2Channels, 4Ω, 1.8V to 5.5V, MSOP, 8Pins
-
DocumentationDatasheet
