ADN4650
Manufacturer

ADI
ChipWorker Part#

CW983388210
Description

5kV rms, 600Mbps Dual Tx or Rx Channel LVDS Isolator
Documentation

Datasheet

ADN4650 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADN4650 Specifications

Attribute	Attribute Value

Part Number	ADN4650
Manufacturer	ADI
ChipWorker Part#	CW983388210
Documentation	Datasheet
	expand all
Product Lifecycle Status	Recommended for New Designs

Product Description

Product Details
The ADN4650 is a signal isolated, low voltage differential signaling (LVDS) buffers that operate at up to 600 Mbps with very low jitter.
The devices integrate Analog Devices, Inc., iCoupler® technology, enhanced for high speed operation, to provide galvanic isolation of the TIA/EIA-644-A compliant LVDS drivers and receivers. This technology allows drop-in isolation of an LVDS signal chain.
For high speed operation with low jitter, the LVDS and isolator circuits rely on a 2.5 V supply. An integrated on-chip low dropout regulator (LDO) can provide the required 2.5 V from an external 3.3 V power supply. The devices are fully specified over a wide industrial temperature range and are available in a 20-lead, wide body SOIC package with 5 kV rms isolation or a 20-lead SSOP package with 3.75 kV rms isolation.
**Applications**
Analog front-end (AFE) isolation
Data plane isolation
Isolated high speed clock and data links
Isolated serial peripheral interface (SPI) over LVDS
### Features and Benefits
5 kV rms/3.75 kV rms LVDS isolator
Complies with TIA/EIA-644-A LVDS standard
Multiple dual-channel configurations
Up to 600 Mbps switching with low jitter
4.5 ns maximum propagation delay
151 ps maximum peak-to-peak total jitter at 600 Mbps
100 ps maximum pulse skew
600 ps maximum part to part skew
2.5 V or 3.3 V supplies
−75 dBc power supply ripple rejection and glitch immunity
±8 kV IEC 61000-4-2 ESD protection across isolation barrier
High common-mode transient immunity: >25 kV/μs
Passes EN55022 Class B radiated emissions limits with 600 Mbps PRBS
Safety and regulatory approvals (20-lead SOIC package)
UL (pending): 5000 V rms for 1 minute per UL 1577
CSA Component Acceptance Notice 5A (pending)
VDE certificate of conformity (pending)
DIN V VDE V 0884-10 (VDE V 0884-10):2006-12
VIORM = 424 V peak
Fail-safe output high for open, short, and terminated input conditions (ADN4651/ADN4652)
Operating temperature range: −40°C to +125°C
Choice of package and isolation options
3.75 kV rms in highly integrated 20-lead SSOP
5 kV rms in 20-lead SOIC with 7.8 mm creepage/clearance
