ADUM3100BRZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADUM3100BRZ
Manufacturer

ADI
ChipWorker Part#

CW582904
Category

Interface Isolator, Digital Isolator
Package

SOIC-8
Description

ANALOG DEVICES ADUM3100BRZ Digital Isolator, 1Channel, 18ns, 3V, 5.5V, SOIC, 8Pins
Documentation

Datasheet

ADUM3100BRZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADUM3100BRZ Specifications

Attribute	Attribute Value

Part Number	ADUM3100BRZ
Manufacturer	ADI
ChipWorker Part#	CW582904
Category	Interface Isolator, Digital Isolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	3.00V (min)
Operating Voltage	3V ~ 5.5V
Rise/Fall Time	3 ns
Output Current	≤170 mA
Supply Current	10 mA
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	240 mW
Data Rate	100 Mbps
Rise Time	3 ns
Isolation Voltage	2500 Vrms
Input Current (Min)	10 μA
Maximum Forward Voltage (Max)	5 V
Fall Time (Max)	3 ns
Fall Time (Max)	3 ns
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	240 mW
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The ADUM3100 series Digital Isolator based on the Analog Devices, Inc., iCoupler® technology. Combining high speed CMOS and monolithic transformer technology, this isolation component provides outstanding performance characteristics superior to alternatives, such as optocoupler devices. Configured as a pin-compatible replacement for existing high speed optocouplers, the ADuM3100 supports data rates as high as 25 and 100Mbps. It operates with a voltage supply ranging from 3 to 5.5V, boasts a propagation delay of <18ns and an edge asymmetry of <2ns and is compatible with temperatures up to 105°C. It operates at very low power, less than 2mA of quiescent current (sum of both sides) and a dynamic current of less than 160µA per Mbps of data rate. Unlike other optocoupler alternatives, it provides dc correctness with a patented refresh feature that continuously updates the output signal.
High data rate of dc to 100Mbps (NRZ)
Low power operation
>25kV/µs High common-mode transient immunity
