ADUM3190TRQZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADUM3190TRQZ
Manufacturer

ADI
ChipWorker Part#

CW752404
Category

Isolation Amplifier IC
Package

QSOP-16
Description

OptoCoupler 1CH 3.3V/5V/9V/12V/15V/18V 16Pin QSOP Tube
Documentation

Datasheet

ADUM3190TRQZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADUM3190TRQZ Specifications

Attribute	Attribute Value

Part Number	ADUM3190TRQZ
Manufacturer	ADI
ChipWorker Part#	CW752404
Category	Isolation Amplifier IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	QSOP-16
Supply Current	1.40 mA
Number of Channels	2 Channel
Number of Positions	16 Position
Power Dissipation	1.64 W
Common Mode Rejection Ratio	70 dB
Bandwidth	400 kHz
Gain Bandwidth Product	10 MHz
Isolation Voltage	2.5 kV
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	400 kHz
Power Dissipation (Max)	1640 mW
Minimum CMRR Range	60dB ~ 75dB
Supply Voltage	3V ~ 20V
Supply Voltage (Max)	20V ~ 30V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	4.01 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The ADUM3190TRQZ is a high stability Isolated Error Amplifier with iCoupler® technology. The ADuM3190 is ideal for linear feedback power supplies. The primary side controllers of the ADuM3190 enable improvements in transient response, power density and stability as compared to commonly used optocoupler and shunt regulator solutions. Unlike optocoupler-based solutions, which have an uncertain current transfer ratio over lifetime and at high temperatures, the ADuM3190 transfer function does not change over its lifetime and it is stable over a wide temperature range of -40 to +125°C. Included in the ADuM3190 is a wideband Op-amp for a variety of commonly used power supply loop compensation techniques. The ADuM3190 is fast enough to allow a feedback loop to react to fast transient conditions and overcurrent conditions. Also included is a high accuracy 1.225V reference to compare with the supply output setpoint.
