ADXL335BCPZ ,Acceleration Sensor - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

222 points

Part No

ADXL335BCPZ
Manufacturer

ADI
ChipWorker Part#

CW453840
Category

Acceleration Sensor
Package

LFCSP-16
Description

Accelerometer Triple ±3g 2.5V/3.3V 270mV/g to 330mV/g 16Pin LFCSP EP Tray
Documentation

Datasheet
Ships from

Moscow
Наличие

2 pcs In Stock
Estimated Price

$ 5.32

Buy ADXL335BCPZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADXL335BCPZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADXL335BCPZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADXL335BCPZ
Manufacturer	ADI
ChipWorker Part#	CW453840
Category	Acceleration Sensor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	LFCSP-16
Supply Voltage (DC)	1.80V (min)
Supply Current	350 µA
Number of Positions	16 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	1.8V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	1.8 V
	expand all
Size-Length	4 mm
Size-Width	4 mm
Size-Height	1.43 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The ADXL335BCPZ is a small, thin, low-power, complete 3-axis Accelerometer with signal conditioned voltage outputs. The product measures acceleration with a minimum full-scale range of ±3g. It can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion, shock or vibration. The user selects the bandwidth of the accelerometer using the CX, CY and CZ capacitors at the XOUT, YOUT and ZOUT pins. Bandwidths can be selected to suit the application, with a range of 0.5Hz to 1600Hz for X and Y axes and a range of 0.5Hz to 550Hz for the Z axis.
3-axis Sensing
Small, Low-profile Package
350µA (Typical) Low Power
10,000g Shock Survival
Excellent Temperature Stability
BW Adjustment with a Single Capacitor per Axis
ESD sensitive device, take proper precaution while handling the device, Although it features patented or proprietary protection circuitry, damage may occur on devices subjected to high energy ESD.
