AGN2004H ,Industrial Relay - Panasonic
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
212 points
-
Part NoAGN2004H
-
ManufacturerPanasonic
-
ChipWorker Part#CW492526
-
CategoryIndustrial Relay
-
PackageDIP
-
DescriptionElectromechanical Relay 4.5VDC 145Ω 1A DPDT(10.6mm 5.7mm 9mm) THT General Purpose Relay
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие1137 pcs In Stock
-
Estimated Price$ 0.58
