AMP01AX ,Instrumentation Amplifier IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

151 points

Part No

AMP01AX
Manufacturer

ADI
ChipWorker Part#

CW11109650
Category

Instrumentation Amplifier IC
Package

CDIP-18
Description

IC OPAMP INSTR 570kHz 18CDIP
Documentation

Datasheet
Ships from

Moscow
Наличие

128080 pcs In Stock
Estimated Price

$ 2.82

Buy AMP01AX

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AMP01AX Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AMP01AX Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AMP01AX
Manufacturer	ADI
ChipWorker Part#	CW11109650
Category	Instrumentation Amplifier IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	18 Pin
Case/Package	CDIP-18
Supply Current	3 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Common Mode Rejection Ratio	85 dB
Slew Rate	4.50 V/μs
Gain Bandwidth Product	570 kHz
Input Offset Voltage	20 µV
Input Bias Current	1 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
3dB Bandwidth	570 kHz
Minimum CMRR Range	80 dB
Supply Voltage (Max)	30V ~ 50V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	24.38 mm
Size-Width	7.87 mm
Size-Height	4.93 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
HK STC License	NLR

Similar & Replacement Parts

Similar products

Product Description

Product Details
The AMP01 is a monolithic instrumentation amplifier designed for high-precision data acquisition and instrumentation applications. The design combines the conventional features of an instrumentation amplifier with a high current output stage. The output remains stable with high capacitance loads (1 μF), a unique ability for an instrumentation amplifier. Consequently, the AMP01 can amplify low level signals for transmission through long cables without requiring an output buffer. The output stage can be configured as a voltage or current generator.
Input offset voltage is very low (20 μV), which generally eliminates the external null potentiometer. Temperature changes have minimal effect on offset; TCVIOS is typically 0.15 μV/°C. Excellent low frequency noise performance is achieved with a minimal compromise on input protection. The bias current is very low, less than 10 nA over the military temperature range. High common-mode rejection of 130 dB, 16-bit linearity at a gain of 1000, and 50 mA peak output current are achievable simultaneously. This combination takes the instrumentation amplifier one step further towards the ideal amplifier.
AC performance complements the superb dc specifications. The AMP01 slews at 4.5 V/μs into capacitive loads of up to 15 nF, settles in 50 μs to 0.01% at a gain of 1000, and boasts a healthy 26 MHz gain bandwidth product. These features make the AMP01 ideal for high speed data acquisition systems.
The gain is set by the ratio of two external resistors over a range of 0.1 to 10,000. A very low gain temperature coefficient of 10 ppm/°C is achievable over the whole gain range. Output voltage swing is guaranteed with three load resistances: 50 Ω, 500 Ω, and 2 kΩ. Loaded with 500 Ω, the output delivers ±13.0 V minimum. A thermal shutdown circuit prevents destruction of the output transistors during overload conditions.
The AMP01 can also be configured as a high performance operational amplifier. In many applications, the AMP01 can be used in place of op amp/power buffer combinations.
### Features and Benefits
Low offset voltage: 50 μV maximum
Very low offset voltage drift: 0.3 μV/°C maximum
Low noise: 0.12 μV p-p (0.1 Hz to 10 Hz)
Excellent output drive: ±10 V at ±50 mA
Capacitive load stability: up to 1 μF
Gain range: 0.1 to 10,000
Excellent linearity: 16-bit at G = 1000
High CMR: 125 dB minimum (G = 1000)
Low bias current: 4 nA maximum
Can be configured as a precision op amp
Output-stage thermal shutdown
Available in die form
