AQY272 ,Solid State Relay - Panasonic
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
181 points
-
Part NoAQY272
-
ManufacturerPanasonic
-
ChipWorker Part#CW3759729
-
CategorySolid State Relay
-
PackageDIP-4
-
DescriptionRelay SSR 50mA 1.5V DC-IN 2A 60V AC-DC-OUT 4Pin DIP Tube
-
DocumentationDatasheet
-
Ships fromMoscow
-
