ATF16V8B-15PU ,FPGA Chip, PAL, CPLD IC - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

165 points

Part No

ATF16V8B-15PU
Manufacturer

Microchip
ChipWorker Part#

CW300630
Category

FPGA Chip, PAL, CPLD IC
Package

PDIP-20
Description

10NS,250Gates EPLD,20Pin PLCC,5V GRN - 15NS, PDIP, IND TEMP, GREEN
Documentation

Datasheet
Ships from

Moscow
Наличие

2120 pcs In Stock
Estimated Price

$ 0.7

Buy ATF16V8B-15PU

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ATF16V8B-15PU Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ATF16V8B-15PU Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ATF16V8B-15PU
Manufacturer	Microchip
ChipWorker Part#	CW300630
Category	FPGA Chip, PAL, CPLD IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	20 Pin
Case/Package	PDIP-20
Frequency	62 MHz
Supply Voltage (DC)	4.50V (min)
Supply Current	55 mA
Number of Gates	150 Gate
Number of I/O Pins	20 IO
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	5 V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
Input Voltage	5 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The ATF16V8B-15PU is a high-performance CMOS Electrically-erasable Programmable Logic Device that utilizes the Atmel proven electrically-erasable flash memory technology. All speed ranges are specified over the full 5.0V ±10% range for industrial temperature range. The ATF16V8B-15PU provides edge-sensing low-power PLD solution with low standby power consumption (5mA typical). The ATF16V8B-15PU powers down automatically to the low-power mode through the input transition detection (ITD) circuitry when the device is idle. The ATF16V8B-15PU incorporate a super set of the generic architectures, which allows direct replacement of the 16R8 family and most 20-pin combinatorial PLDs. Eight outputs are each allocated eight product terms. Three different modes of operation, configured automatically with software, allow highly complex logic functions to be realized.
