Part No

ATV12H075M2
Manufacturer

Schneider Electric
ChipWorker Part#

CW57715593
Category

Motors, Drive
Package

200
Description

Frequency converter ALTIVAR ATV12 0.75kW, 200. . 0.24VAC Single phase, ATV12H075M2, Schneider Electric
Documentation

Datasheet

ATV12H075M2 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ATV12H075M2 Specifications

Attribute	Attribute Value

Part Number	ATV12H075M2
Manufacturer	Schneider Electric
ChipWorker Part#	CW57715593
Category	Motors, Drive
Documentation	Datasheet
Case/Package	200
Supply Voltage (DC)	230V (max)
Current Rating	8.5 A
Power Rating	750 W
Output Voltage	≤230 V
Output Current	4.20 A
Output Voltage (Max)	240 V
Output Current (Max)	4.2 A
Voltage Rating	230 V
Supply Voltage	230 V
Supply Voltage (Max)	240 VAC
Supply Voltage (Min)	200 VAC
	expand all
Size-Length	143 mm
Size-Width	72 mm
Size-Height	130 mm
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

The ATV12H075M2 from Schneider Electric is a single phase, variable speed asynchronous motor drive with 0.75KW power and integrated EMC filter. This drive works at rated supply voltage ranging from 200V to 240V and standard dimension of 143mm height, 72mm width and 131.2mm depth. This simple machine used with centrifugal pumps and fans.
Modbus communication port protocol
1 RJ45 for Modbus on front face and 2 wire RS 485 for Modbus physical interface
Featured with heat sink assembly
Without built-in fan
Supply frequency of 50Hz/60Hz and nominal switching frequency of 4kHz
Product weight is 0.8Kg
Vertical operating position
CSA, C-Tick, GOST, NOM and UL certified
IP20 without blanking plate on upper part
Ambient air temperature for operation range from 40°C to 60°C with current derating 2.2% /°C
