B2B-PH-SM4-TB(LF)(SN) ,Wire to Board Connector - JST

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

241 points

Part No

B2B-PH-SM4-TB(LF)(SN)
Manufacturer

JST
ChipWorker Part#

CW60217
Category

Wire to Board Connector
Package

-
Description

Wire-To-Board Connector, 2mm, 2Contacts, Header, PH Series, Surface Mount, 1Rows
Documentation

Datasheet
Ships from

Moscow
Наличие

3270 pcs In Stock
Estimated Price

$ 0.19

Buy B2B-PH-SM4-TB(LF)(SN)

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

B2B-PH-SM4-TB(LF)(SN) Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

B2B-PH-SM4-TB(LF)(SN) Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	B2B-PH-SM4-TB(LF)(SN)
Manufacturer	JST
ChipWorker Part#	CW60217
Category	Wire to Board Connector
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package	-
Pin Pitch	2.00 mm
Number of Contacts	2 Contact
Gender	Male
Contact Plating	Tin
Voltage Rating (AC)	100 V
Current Rating	2 A
Insulation Resistance	1000 MΩ
Number of Rows	1 Row
Flammability Rating	UL 94 V-0
Number of Positions	2 Position
Current Rating (Max)	2 A
Voltage Rating	100 V
Maximum Contact Resistance (Max)	20 mΩ
	expand all
Size-Length	7.95 mm
Size-Width	5.00 mm
Size-Height	6.6 mm
Housing Color	Ivory
Color	Natural
Contact Material	Copper Alloy
Material	Polyamide (PA)
Operating Temperature	-25℃ ~ 85℃
Housing Material	Nylon
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Non-Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The PH series top entry, surface mount shrouded header from JST are 2.0mm pitch, single row wire to board disconnect crimp style connectors. These are thin, low profile, highly reliable connectors with 8.0mm mounting height and 4.5mm width. Fully shrouded header has walls on all four sides to prevent improper connection to the mating housing and to prevent the instruction of flux and other contaminants. Its housing is made up of heat resistant resin so that it is not adversely affected during reflow soldering. Because of its compact size and surface mount termination, this connector meets the demand for high-density mounting of components inside electronic products.
Current rating of 2A
Voltage rating of 100VAC/DC
Temperature range from -25°C to 85°C
Wire size of 32AWG to 24AWG
Number of contacts varies from 2 to 16 pins
Contact material is brass
Tin plated contact
UL, CSA and TUV certified
