BSC220N20NSFDATMA1 - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

BSC220N20NSFDATMA1
Manufacturer

Infineon
ChipWorker Part#

CW376925872
Package

TSON
Description

Trans MOSFET N-CH 200V 52A 8-Pin TSON EP T/R
Documentation

Datasheet

BSC220N20NSFDATMA1 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

BSC220N20NSFDATMA1 Specifications

Attribute	Attribute Value

Part Number	BSC220N20NSFDATMA1
Manufacturer	Infineon
ChipWorker Part#	CW376925872
Documentation	Datasheet
Number of Pins	8 Pin
Case/Package	TSON
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	0.0177 Ω
Power Dissipation	214 W
Threshold Voltage	3 V
Drain to Source Voltage (Vds)	200 V
Rise Time	7 ns
Input Capacitance (Ciss)	2770pF @100V(Vds)
Fall Time	10 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	214000 mW
	expand all
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead

Product Description

N-Channel 200V 52A 214W (Tc) Surface Mount PG-TSON-8-3
