BSS138 ,MOSFET, MOSFET Transistor - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

257 points

Part No

BSS138
Manufacturer

Fairchild
ChipWorker Part#

CW2002896
Category

MOSFET, MOSFET Transistor
Package

SOT-23-3
Description

Trans MOSFET N-CH 50V 0.2A 3Pin SOT-23 T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

5307 pcs In Stock
Estimated Price

$ 0.99

Buy BSS138
