BT139-800 ,TRIAC Diode, TRIAC - NXP

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

72 points

Part No

BT139-800
Manufacturer

NXP
ChipWorker Part#

CW87391790
Category

TRIAC Diode, TRIAC
Package

TO-220
Description

NXP BT139-800 Triac, 800V, 16A, TO-220AB, 0.7V, 5W
Documentation

Datasheet
Ships from

Moscow
Наличие

5278 pcs In Stock
Estimated Price

$ 0.1

Buy BT139-800

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

BT139-800 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

BT139-800 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	BT139-800
Manufacturer	NXP
ChipWorker Part#	CW87391790
Category	TRIAC Diode, TRIAC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220
Voltage Rating (DC)	800 V
Current Rating	16.0 A
Number of Positions	3 Position
Holding Current	45.0 mA
Holding Current (Max)	45 mA
Operating Temperature (Max)	150 ℃
	expand all
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The BT139-800 from NXP is a planar passivated four quadrant triac in 3 pin SOT78 (TO-220AB) plastic package. Triac are intended for use in applications requiring high bidirectional transient and blocking voltage capability, high thermal cycling performance.
High blocking voltage capability
Less sensitive gate for high noise immunity
Planar passivated for voltage ruggedness and reliability
Maximum gate trigger voltage of 1V
Maximum holding current is 45mA
RMS onstate current is 16A
Maximum junction temperature of 125°C
Peak gate power of 5W
Non repetitive peak on-state current of 155A
Repetitive peak off state voltage of 800V

expand all
