C20F.0001 ,Power Entry Module - Schurter

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

89 points

Part No

C20F.0001
Manufacturer

Schurter
ChipWorker Part#

CW5919233
Category

Power Entry Module
Description

Connector: AC supply; socket; male; 20A; 250VAC; IEC 60320; 0.3mH
Documentation

Datasheet
Ships from

Moscow
Наличие

77 pcs In Stock
Estimated Price

$ 32.82

Buy C20F.0001

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

C20F.0001 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

C20F.0001 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	C20F.0001
Manufacturer	Schurter
ChipWorker Part#	CW5919233
Category	Power Entry Module
Documentation	Datasheet
Mounting Style	Panel, Quick Connect, Solder
Number of Contacts	3 Contact
Gender	Male
Frequency	50Hz ~ 60Hz
Voltage Rating (DC)	250 V
Voltage Rating (AC)	250 V
Current Rating	20 A
Capacitance	100 nF
Flammability Rating	UL 94 V-0
Number of Positions	3 Position
Inductance	0.3 mH
Current Rating (Max)	20 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
Voltage Rating (Max)	250 VAC
Voltage Rating	250 VAC
Voltage Rating (AC Max)	250 V
	expand all
Size-Length	30 mm
Size-Width	78.8 mm
Size-Height	53 mm
Color	Black
Operating Temperature	-25℃ ~ 85℃
Housing Material	Thermoplastic
Product Lifecycle Status	Active
Packaging	Box
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2016/06/20
HTS Code	8536698000
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The C20F.0001 is a panel-mount Power Entry Module with line filter. It features screw-on version from front or rear side and snap-in version from front side and solder contact termination. The module is made with the black thermoplastic housing. This is suitable for appliances with protection class I according to IEC 61140. The module also features compact design with optimal shielding suitable for assembly in metal plated plastic housings.
Version with class X1 and X2 capacitors
Universal line filter for standard applications
IP40 Protection rating
-25 to 85°C Operating temperature range
