DAC08CPZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

DAC08CPZ
Manufacturer

ADI
ChipWorker Part#

CW377396
Category

Digital to Analog, DAC IC
Package

DIP-16
Description

ANALOG DEVICES DAC08CPZ Digital to Analog Converter, 8Bit, 11.8MSPS, Parallel, ± 4.5V to ± 18V, DIP, 16Pins
Documentation

Datasheet

DAC08CPZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

DAC08CPZ Specifications

Attribute	Attribute Value

Part Number	DAC08CPZ
Manufacturer	ADI
ChipWorker Part#	CW377396
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Number of Outputs	1 Output
Supply Current	-6.50 mA
Number of Channels	1 Channel
Number of Positions	16 Position
Number of Bits	8 Bit
Power Dissipation	174 mW
Sample Rate	11.8 Msps
Resolution (Bits)	8.0 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	174 mW
Number of DACs	1 DAC
Supply Voltage (Max)	18 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	20.07 mm
Size-Width	6.35 mm
Size-Height	3.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17

Product Description

The DAC08CPZ is a 8-bit Multiplying D/A Converter that provides very high speed performance coupled with outstanding applications flexibility. Advanced circuit design achieves 85ns settling times with very low "glitch" energy and at low power consumption. Monotonic multiplying performance is attained over a wide 20-to-1 reference current range. Matching to within 1 LSB between reference and full-scale currents eliminates the need for full scale trimming in most applications. Direct interface to all popular logic families with full noise immunity is provided by the high swing, adjustable threshold logic input. High voltage compliance complementary current outputs are provided, increasing versatility and enabling differential operation to effectively double the peak-to-peak output swing. In many applications, the outputs can be directly converted to voltage without the need for an external op amp.
Fast settling output current (85ns)
Full-scale current pre-matched to ±1 LSB
Direct interface to TTL, CMOS, ECL, HTL, PMOS
Nonlinearity to 0.1% maximum over-temperature range
High output impedance and compliance (-10 to +18V)
Complementary current outputs
Wide range multiplying capability (1MHz bandwidth)
Low FS current drift (±10ppm/°C)
Low power consumption (33mW at ±5V)
ESD sensitive device, take proper precaution while handling the device.
