DRV8332DKDR Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | DRV8332DKDR |
| Manufacturer | TI |
| ChipWorker Part# | CW19108033 |
| Category | Motor Driver |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 36 Pin |
| Case/Package | BSSOP-36 |
| Number of Outputs | 1 Output |
| Output Voltage | 52.5 V |
| Output Current | 8 A |
| Number of Positions | 36 Position |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 10.8V ~ 13.2V |
| Supply Voltage (Max) | 13.2 V |
| Supply Voltage (Min) | 10.8 V |
| expand all | |
| Operating Temperature | -40℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
Product Description
- DESCRIPTION
- The DRV8312/32 are high performance, integrated three phase motor drivers with an advanced
- protection system. Because of the low RDS(on) of the power MOSFETs and intelligent gate drive design, the efficiency of these motor drivers can be up to 97%, which enables the use of smaller power supplies and heatsinks, and are good candidates for energy efficient applications.
- FEATURES
- • High-Efficiency Power Stage (up to 97%) with Low RDS(on) MOSFETs (80 mΩ at TJ = 25°C)
- • Operating Supply Voltage up to 50 V (70 V Absolute Maximum)
- • DRV8312 (power pad down): up to 3.5 A Continuous Phase Current (6.5 A Peak)
- • DRV8332 (power pad up): up to 8 A Continuous Phase Current ( 13 A Peak)
- • Independent Control of Three Phases
- • PWM Operating Frequency up to 500 kHz
- • Integrated Self-Protection Circuits Including Undervoltage, Overtemperature, Overload, and
- Short Circuit
- • Programmable Cycle-by-Cycle Current Limit Protection
- • Independent Supply and Ground Pins for Each Half Bridge
- • Intelligent Gate Drive and Cross Conduction Prevention
- • No External Snubber or Schottky Diode is Required
- APPLICATIONS
- • BLDC Motors
- • Three Phase Permanent Magnet Synchronous Motors
- • Inverters
- • Half Bridge Drivers
- • Robotic Control Systems
