DS2413P+ ,Active Chip - Maxim Integrated

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

127 points

Part No

DS2413P+
Manufacturer

Maxim Integrated
ChipWorker Part#

CW5058134
Category

Active Chip
Package

TSOC-6
Description

Programmable Timer, 1 Timer(s), PDSO6, 0.15INCH, ROHS COMPLIANT, TSOC-6
Documentation

Datasheet
Ships from

Moscow
Наличие

3762 pcs In Stock
Estimated Price

$ 2.07

Buy DS2413P+

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

DS2413P+ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

DS2413P+ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	DS2413P+
Manufacturer	Maxim Integrated
ChipWorker Part#	CW5058134
Category	Active Chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	TSOC-6
Supply Voltage (DC)	2.80V (min)
Contacts Type	SPST
Number of Channels	2 Channel
Number of Positions	6 Position
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	2.8.5.25 VDC
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	2.8 V
	expand all
Size-Length	4 mm
Size-Width	3.89 mm
Size-Height	1.35 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

The DS2413P+ is a 1-wire dual channel addressable switch in 6 pin TSOC package. This is a dual channel programmable I/O 1-wire chip. The PIO outputs are configured as open-drain and provide up to 20mA continuous sink capability and off-state operating voltage up to 28V. Control and sensing of PIO pins is performed with a dedicated device level command protocol. To provide a high level of fault tolerance in the end application, 1-wire IO and PIO pins are all capable of withstanding continuous application of voltages up to 28V max. Communication and operation of the DS2413 is performed with single contact Maxim/Dallas 1-wire serial interface. It is used in LED control, accessory identification and control, general purpose input/output, key-pick systems and industrial controllers.
Supply voltage range is 2.8V to 5.25V
Operating temperature range from 0°C to 70°C
Controls dual programmable high voltage, high current I/O port pins from a single micro port pin
On-resistance of PIO pull-down transistor 20 ohm max, OFF resistance 1Mohm min
Minimalist 1-wire interface lowers cost and interface complexity
Communicates to host with a single digital signal at 14.9Kb or 100Kbps
Switchpoint hysteresis and filtering to optimize performance in presence of noise
Factory lasered unique 64bit ROM serial number
High ESD immunity of 1-wire IO Pin, 8KV HBM typical

expand all
