ERJ14YJ561U - Panasonic

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ERJ14YJ561U
Manufacturer

Panasonic
ChipWorker Part#

CW113027876
Category

Chip SMD Resistor
Package

1210
Description

1210 560Ω ±5% ±200ppm/℃
Documentation

Datasheet

ERJ14YJ561U Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ERJ14YJ561U Specifications

Attribute	Attribute Value

Part Number	ERJ14YJ561U
Manufacturer	Panasonic
ChipWorker Part#	CW113027876
Category	Chip SMD Resistor
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package (SI)	3225
Case/Package	1210
Voltage Rating (DC)	200 V
Power Rating	500 mW
Part Family	ERJ14
Resistance	560 Ω
Resistance Tolerance	±5 %
Voltage Rating	200 V
	expand all
Size-Length	3.20 mm
Size-Width	2.50 mm
Size-Height	600 µm
Operating Temperature	-55℃ ~ 155℃
Temperature Coefficient	±200 ppm/℃
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
Minimum Packing Quantity	40000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Product Description

RES SMD 560 OHM 5% 1/2W 1210
