FDMF3035
Manufacturer

ON Semiconductor
ChipWorker Part#

CW48592978
Package

PQFN-31
Description

Driver 4A 1Out High Side/Low Side Inv/Non-Inv 31Pin PQFN EP T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

29806 pcs In Stock
Estimated Price

$ 0.91

Buy FDMF3035

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

FDMF3035 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

FDMF3035 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	FDMF3035
Manufacturer	ON Semiconductor
ChipWorker Part#	CW48592978
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	31 Pin
Case/Package	PQFN-31
Number of Outputs	1 Output
Fall Time (Max)	8 ns
Fall Time (Max)	8 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 5.5V
	expand all
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Product Description

The SPS family is Fairchild’s next-generation, fully optimized, ultra-compact, integrated MOSFET plus driver power stage solution for high-current, highfrequency synchronous buck, DC-DC applications. The FDMF3035 integrates a driver IC with a bootstrap Schottky diode and two power MOSFETs into a thermally enhanced, ultra-compact 5 mm x 5 mm package.With an integrated approach, the SPS switching power stage is optimized for driver and MOSFET dynamic performance, minimized system inductance, and power MOSFET RDS(ON). The SPS family uses Fairchild"s highperformance PowerTrench® MOSFET technology, which reduces switch ringing, eliminating the need for a snubber circuit in most buck converter applications.A driver IC with reduced dead times and propagation delays further enhances the performance. The FDMF3035 supports diode emulation (using FCCM pin)for improved light-load efficiency. The FDMF3035 also provides a 3-state 5 V PWM input for compatibility with a wide range of PWM controllers.
Features
---
|
Supports PS4 Mode for IMVP-8
Compatible with Intersil IMVP-8 PWM Controller
Ultra-Compact 5 mm x 5 mm PQFN Copper-Clip Package with Flip Chip Low-Side MOSFET
High Current Handling: 50 A
3-state 5 V PWM Input Gate Driver
Low Shutdown Current : IVCC < 3 uA
Diode Emulation for Enhanced Light Load Efficiency
Fairchild PowerTrench® MOSFETs for Clean Voltage Waveforms and Reduced Ringing
Fairchild SyncFET™ Technology (Integrated Schottky Diode) in Low-Side MOSFET
Integrated Bootstrap Schottky Diode
Optimized / Extremely Short Dead-Times
Under-Voltage Lockout (UVLO) on VCC
Optimized for Switching Frequencies up to 1.5 MHz
Operating Ambient Temperature Range: -40°C to +125°C
Fairchild Green Packaging and RoHS Compliance
