Part NoFDPF15N65
-
ManufacturerFairchild
-
ChipWorker Part#CW56634104
-
CategoryMOSFET, MOSFET Transistor
-
PackageTO-220-3
-
DescriptionPower Field-Effect Transistor, 15A I(D), 650V, 0.44Ω, 1Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB, LEAD FREE, TO-220F, 3Pin
-
DocumentationDatasheet
