GBU4J - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

GBU4J
Manufacturer

ON Semiconductor
ChipWorker Part#

CW4684800
Category

Bridge Rectifier
Package

SIP-4
Description

RECT BRIDGE GPP 4A 600V GBU
Documentation

Datasheet

GBU4J Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

GBU4J Specifications

Attribute	Attribute Value

Part Number	GBU4J
Manufacturer	ON Semiconductor
ChipWorker Part#	CW4684800
Category	Bridge Rectifier
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	SIP-4
Number of Positions	4 Position
Forward Voltage	1 V
Power Dissipation	8000 mW
Forward Current	4 A
Max Forward Surge Current (Ifsm)	150 A
Maximum Forward Voltage (Max)	1 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	8000 mW
	expand all
Size-Length	22.3 mm
Size-Width	3.56 mm
Size-Height	18.8 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

The GBU4J is a 4-pin single-phase Bridge Rectifier Diode features a reliable construction utilizing moulded plastic technique. It has glass-passivated junction and ideal for printed circuit board.
150A Peak surge overload rating
420V Maximum RMS bridge input voltage
-55 to 150°C Operating junction temperature range
