HCPL-7800A-000E ,Isolation Amplifier IC - Broadcom

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

73 points

Part No

HCPL-7800A-000E
Manufacturer

Broadcom
ChipWorker Part#

CW9333561
Category

Isolation Amplifier IC
Package

DIP-8
Description

BROADCOM LIMITED HCPL-7800A-000E Isolation Amplifier, Optically, 1 Amplifier, 0.3mV, 3.75kV, 4.5V to 5.5V, DIP, 8Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

10 pcs In Stock
Estimated Price

$ 6.39

Buy HCPL-7800A-000E

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

HCPL-7800A-000E Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

HCPL-7800A-000E Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	HCPL-7800A-000E
Manufacturer	Broadcom
ChipWorker Part#	CW9333561
Category	Isolation Amplifier IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Current	10.9 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	76 dB
Bandwidth	100 kHz
Isolation Voltage	3.75 kV
Input Offset Voltage	300 µV
Input Bias Current	500 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	100 kHz
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	9.8 mm
Size-Width	6.35 mm
Size-Height	3.56 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The HCPL-7800A-000E is an Isolation Amplifier for current sensing in electronic motor drives. The high CMR capability of isolation amplifier provides the precision and stability needed to accurately monitor motor current in high noise motor control environments, providing for smoother control in various types of motor control applications. In a typical implementation the motor current flows through an external resistor and the resulting analogue voltage drop is sensed by the amplifier. A differential output voltage is created on the other side of the amplifier optical isolation barrier. It is designed to ignore very high common-mode transient slew rates.
15kV/µs Common-mode rejection at VCM = 1000V
Advanced sigma-delta A/D converter technology
Compact and auto-insertable
Fully differential circuit topology
ESD sensitive device, take proper precaution while handling the device.
