Part No

HMC536MS8GE
Manufacturer

ADI
ChipWorker Part#

CW1014500
Category

RF Module
Package

MSOP-8
Description

RF Switch 0MHz to 6GHz 23dB 8Pin MSOP
Documentation

Datasheet

HMC536MS8GE Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

HMC536MS8GE Specifications

Attribute	Attribute Value

Part Number	HMC536MS8GE
Manufacturer	ADI
ChipWorker Part#	CW1014500
Category	RF Module
Documentation	Datasheet
Number of Pins	8 Pin
Case/Package	MSOP-8
Frequency	6000 MHz
Number of Positions	8 Position
Power Dissipation	867 mW
Test Frequency	6 GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	867 mW
	expand all
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99

Product Description

Product Details
The HMC536MS8G(E) is a DC to 6 GHz GaAs MMIC T/R switch in an 8 lead MSOP8G surface mount package with an exposed ground paddle. The switch is ideal for cellular/PCS/3G basestation applications featuring low 0.5 dB insertion loss and +55 dBm input IP3. Power handling is excellent up through 6 GHz with the switch offering a P0.1dB compression point of +29 dBm at +3 volts control. On-chip circuitry allows positive voltage control of 0/+3 volts or 0/+5 volts at very low DC currents.
Applications
Cellular/PCS/3G Infrastructure
ISM/MMDS/WiMAX
CATV/CMTS
Test Instrumentation
### Features and Benefits
Input P0.1dB: +34 dBm @ +5V
Insertion Loss: 0.5 dB
Positive Control: +3V or +5V
MS8G SMT Package, 14.8 mm²
Isolation: 27 dB
Very Fast Switching Speed
