HMC913 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

HMC913
Manufacturer

ADI
ChipWorker Part#

CW77411878
Category

Amplifier chip
Package

Die
Description

Video Amplifiers SDLVA Chip, 0.6 - 20GHz
Documentation

Datasheet

HMC913 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

HMC913 Specifications

Attribute	Attribute Value

Part Number	HMC913
Manufacturer	ADI
ChipWorker Part#	CW77411878
Category	Amplifier chip
Documentation	Datasheet
Number of Pins	22 Pin
Case/Package	Die
Frequency	600MHz ~ 20GHz
Supply Current	80 mA
Test Frequency	600 MHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	3.3 V
	expand all
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead

Product Description

Product Details
The HMC913 is a Successive Detection Log Video Amplifier (SDLVA) which operates from 0.6 to 20 GHz. The HMC913 provides a logging range of 59 dB. This device offers typical fast rise/fall times of 5/10 ns and a superior delay time of only 14 ns. The HMC913 log video output slope is typically 14 mV/dB. Maximum recovery times are less than 30 ns. Ideal for high speed channelized receiver applications, the HMC913 operates from a single +3.3 V supply, and consumes only 80 mA. All data shown herein is measured with the chip in a 50 Ohm environment and contacted with RF probes.
Applications
EW, ELINT & IFM Receivers
DF Radar Systems
ECM Systems
Broadband Test & Measurement
Power Measurement & Control Circuits
Military & Space Applications
### Features and Benefits
High Logging Range: 59 dB
(-54 to +5 dBm) @ 18 GHz
Output Frequency Flatness: ±1.5 dB
Log Linearity: ±1 dB
Fast Rise/Fall Times: 5/10 ns
Single Positive Supply: +3.3V
ESD Sensitivity (HBM): Class 1A
