IR4427 - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IR4427
Manufacturer

Infineon
ChipWorker Part#

CW58528328
Category

FET Driver
Package

PDIP-8
Description

MOSFET DRVR 3.3A 2Out Lo Side Non-Inv 8Pin PDIP
Documentation

Datasheet

IR4427 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IR4427 Specifications

Attribute	Attribute Value

Part Number	IR4427
Manufacturer	Infineon
ChipWorker Part#	CW58528328
Category	FET Driver
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Voltage (DC)	20.0V (max)
Rise/Fall Time	15ns, 10ns
Number of Outputs	2 Output
Output Voltage	≥6.00 V
Part Family	IR4427
Fall Time (Max)	25 ns
Fall Time (Max)	35 ns
Supply Voltage	6V ~ 20V
	expand all
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Product Description

Summary of Features:
Gate drive supply range from 6 to 20 V
CMOS Schmitt-triggered inputs
Matched propagation delay for both channels
Outputs in phase with inputs (IR4427)
Outputs out of phase with inputs (IR4426 Output OUTA out of phase with input and OUTB in phase with input (IR4428
