IRF9540N - International Rectifier

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IRF9540N
Manufacturer

International Rectifier
ChipWorker Part#

CW93914910
Category

P Channel MOSFET, CH Transistor
Package

TO-220
Description

Trans MOSFET P-CH 100V 23A 3Pin(3+Tab) TO-220AB
Documentation

Datasheet

IRF9540N Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IRF9540N Specifications

Attribute	Attribute Value

Part Number	IRF9540N
Manufacturer	International Rectifier
ChipWorker Part#	CW93914910
Category	P Channel MOSFET, CH Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220
Voltage Rating (DC)	-100 V
Current Rating	-23.0 A
Drain to Source Resistance (on) (Rds)	117 mΩ
Polarity	P-Channel
Power Dissipation	140 W
Part Family	IRF9540N
Drain to Source Voltage (Vds)	-100 V
Breakdown Voltage (Drain to Source)	-100 V
Breakdown Voltage (Gate to Source)	±20.0 V
Continuous Drain Current (Ids)	-23.0 A
Rise Time	67.0 ns
	expand all
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
