L78L05CD13TR - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

L78L05CD13TR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW873496
Category

Voltage Regulator
Package

SOIC-8
Description

Linear Voltage Regulator, 7805, Fixed, 10V To 30V In, 5V And 0.1A Out, SOIC-8
Documentation

Datasheet

L78L05CD13TR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

L78L05CD13TR Specifications

Attribute	Attribute Value

Part Number	L78L05CD13TR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW873496
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Number of Outputs	1 Output
Input Voltage (DC)	30.0V (max)
Output Voltage	5 V
Output Current	100 mA
Supply Current	5.5mA ~ 6mA
Number of Positions	8 Position
Quiescent Current	6 mA
voltage rating	1.7V @40mA
Input Voltage (Max)	30 V
Input Voltage (Min)	10 V
Output Voltage (Min)	5 V
Output Current (Max)	100 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	0 ℃
Accuracy	±8 %
Input Voltage	30 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	0℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

This standard L78L05CD13TR linear regulator from STMicroelectronics acts like a variable resistor to maintain a steady voltage level. Its typical dropout voltage at current is 1.7@40mA V. It has an overall accuracy of ±8 %. This voltage regulation device"s single output can produce a current up to 0.1 A. It only needs a voltage that does not exceed 30 V to effectively power your circuit. With a fixed output that has a voltage of 5 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 60mV and line regulation of 200mV. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of 0 °C to 125 °C. Its polarity is positive.
