LADN02 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LADN02
Manufacturer

Schneider Electric
ChipWorker Part#

CW16224517
Category

Industrial Relay
Description

"Schneider Electric / Square D LADN02 IEC Auxiliary Contact Block 690V AC At 25 - 400Hz, 10A, 2NC, Front Moun...
Documentation

Datasheet

LADN02 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LADN02 Specifications

Attribute	Attribute Value

Part Number	LADN02
Manufacturer	Schneider Electric
ChipWorker Part#	CW16224517
Category	Industrial Relay
Documentation	Datasheet
Mounting Style	Snap-In
Number of Contacts	2 Contact
Supply Voltage (DC)	690 V
Current Rating	10 A
Contacts Type	DPST-NC
Contact Current Rating	10 A
Operating Temperature (Max)	60 ℃
Operating Temperature (Min)	-5 ℃
Supply Voltage	690 V
	expand all
Operating Temperature	-5℃ ~ 60℃
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16

Product Description

The LADN02 is a 2NC front mounting Auxiliary Contact Block with screw clamp terminals and instantaneous operation. It is compatible with the TeSys D/F CR1F contactors and control relays.
30M Cycles mechanical durability
5mA Minimum switching current
17V Minimum switching voltage
1.5ms Overlap time
>10MR Insulation resistance

expand all
