LC1D258G7 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LC1D258G7
Manufacturer

Schneider Electric
ChipWorker Part#

CW272214303
Description

Contactor, Non-Reversing, 600VAC, 25A, 4Pole, 120VAC Coil, DIN Rail, TeSys D
Documentation

Datasheet

LC1D258G7 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LC1D258G7 Specifications

Attribute	Attribute Value

Part Number	LC1D258G7
Manufacturer	Schneider Electric
ChipWorker Part#	CW272214303
Documentation	Datasheet
Mounting Style	DIN Rail
Operating Voltage	600 VAC
Current Rating	40 A
Contacts Type	4PDT
Contact Current Rating	40 A
Coil Voltage	120 VAC
Coil Voltage (AC)	120 V
Operating Temperature (Max)	60 ℃
Operating Temperature (Min)	-5 ℃
Voltage Rating	690VAC, 300VDC
	expand all
Size-Length	105 mm
Operating Temperature	-5℃ ~ 60℃
RoHS	RoHS Compliant

Product Description

Non-reversing contactor used for motor control, 75mm DIN rail mounting.
